Silver Welding 14" Wet Diamond Saw Blade For Cutting Granite Marble Concrete

Product DescriptionDiamond Circular Saw Blade adopt High-Grade diamond,Metal powder.Make different formula for different stone. Here's the Technical data of our 400mm(16")Diamond Circular Saw Blade For Granite Marble.Out Diameter:400mm (Other szie is available upon your request)Inner Hole:50mm/60mmType:Normal Saw Blade/Silent Saw BladeDimension of Diamond Segment: 40x3.4x15mm for granite  40x3.6x10mm for marbleCapacity: can cut at least 300-400 square meters of hard Granite Marble
Premium quality bridge saw diamond blades for granite cutting by HUAZUAN, choose size from 12 in. to 24 in. Designed for high sawing performance and long tool life. Optimized for cutting granite countertop slabs. Ideal for professional stone fabricators
15mm Segments with Grade A diamond crystals for aggressive sawing and extended life
Silent core for noise reduction and less vibration
Suitable for wet use only
For bridge saw with 60mm / 50mm arbor onlySpecifications

Out Diameter Bore Diameter(mm) Dimension of teeth(mm) NO. of Teeth Inch mm Thickness Height 10'' 250 50/60 2.6/2.8 8,10,12,15 17 12'' 300 50/60 2.8/3.0 8,10,12,15 21 14'' 350 50/60 3.0/3.2 8,10,12,15 24 16'' 400 50/60 3.4/3.6 8,10,12,15 28 18'' 450 50/60 3.8/4.2 8,10,12,15 32 20'' 500 50/60 4.0/4.2 8,10,12,15 36 22'' 550 50/60 4.6/4.8 8,10,12,15 40 24'' 600 50/60 4.6/4.8 8,10,12,15 42 26'' 650 50/60 5.0/5.2 8,10,12,15 46 28'' 700 50/60 5.0/5.2 8,10,12,15 50 30'' 750 50/60 5.2/5.6 8,10,12,15 54 32'' 800 50/60/80 5.5/6.0 8,10,12,15 57  Other size is available as per requst.Product PicturesApplication Product ProcessPackaging & Shipping Company Information FAQ                                                                                   How Do Diamond Blades Work? Understanding how a diamond blade works will help you choose a blade with the right characteristics and cutting quality for your needs. Here are the four basic blade components:The metal core, a precision-engineered steel disk with a segmented rim that holds the diamonds.The synthetic diamond crystals, the sharp cutting teeth that slice through the concrete.The matrix, a metal bond that holds the diamond particles in place until they wear away.The weld, which attaches the cutting segments to the core (most segments are laser welded or soldered). The exposed diamonds on the surface of each segment do the cutting, using abrasive action to slice through material as the blade rotates at high speeds. As the diamonds at the surface become dull through use, the matrix begins to shed away to release the worn diamond crystals and expose new, sharp diamonds embedded within the matrix.The most important fact to know is that the hardness of the matrix controls how quickly a blade wears. Here's the basic rule: A diamond blade used to cut soft, abrasive materials (such as uncured, green concrete) should have a hard metal bond so the exposed diamonds are fully utilized before they shed away. Conversely, a blade for cutting hard, nonabrasive concrete should have a soft bond to allow for easier erosion of the matrix, which will ensure exposure of new, sharp diamonds when you need them.Contact us  Contact us if you need more details on Granite Wet Cutting Saw Blade. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Granite Saw Blade、Diamond Saw Blade For Granite. If these products fail to match your need, please contact us and we would like to provide relevant information. Product Categories : Diamond Saw Blade > Diamond blade for granite Email to this supplier *Subject: To: *Messages: Your message must be between 20-8000 characters Premium Related Products how much do laser cutters cost Diamond Blade PCB for Aluminium V Groove Blade 9 inchi hand held polishing pads for glass Diamond Cutting Disc for Granite Marble Stone Hydraulic power tool for rock cutting in mines Other Products Quality Stone Diamond Saw Blade for Cutting Granite Marble Quartz Contact Now 500mm Diamond Round Cutting Blade for Granite Stone Processing Contact Now 350mm-450mm Stone Cutting Tool Silent Cutting Diamond Circular Saw Blade Contact Now Huazuan diamond tool saw blade of diamond concrete blades for concrete cutting Contact Now Hot Products Durable Diamond Wire Tools for Granite QuarryDiamond Core Drill Bit Series for Stones and Concrete2t Grass &Brush Cutting Steel Saw BladeTop Quality Folding Hand Saw/Garden SawDry Flexible Polishing PadTct Saw Blade /Brush Cutter for Cutting GrassProfessional Tungsten Carbide Tipps Circular Saw Blade for WoodDiamond Grinding Disc 10 Segments for Concrete FloorT Seg Concave Blades100mm Aluminium Body Diamond Turbo Cup WheelHot Sales Diamond Router Bits for GraniteProfessional Diamond Bush Hammer Tools PartHot Sell Abrasive Antique Brush for Granite3 Step Diamond Wet Polishing Pad for GraniteDurable Diamond Fickert for Granite GrindingSmooth Cutting Diamond Segment for Sandstone Cutting High Quality Granite Wet Cutting Saw Blade, Granite Saw Blade, Diamond Saw Blade For Granite Suppliers in China Home All Products Contact Sitemap Copyright © 2023 www.nsblades.com All rights reserved.
